MULTIPARKER 730

By the use of a lift and shuttle system, faster access times are ensured with Multiparker 730.

The Multiparker 730 provides space saving parking by stacking cars side by side and on top of each other to a high rack. Crosswise parking in 3 rows left and right of the shuttle. For very fast access, shuttles runs independently and simultaneously on each level between parking places and lift. For each parking level having a large number of parking places, it is possible to install two or more shuttles. High performance is supported by an integrated quick-pallet-change system, for simultaneous replacement of the loaded and empty pallets.

Specifications

  • As tower and/or pit version
  • Automatically operated parking system for 10 to more than 100 cars
  • Variable system length available
  • Multiple row arrangement with up to 2 parking rows behind each other
  • Well adaptable to individual project requirements
  • Safe for user and cars (no narrow ramps, dark stairs, no damage caused by theft or vandalism)
  • Customazible arrangement of the lifts and transfer areas
  • Integrated turntable option available
  • Very fast access time by use of a quick-change pallet system
  • No ramps and driving lanes
  • No costly illumination and ventilation necessary
  • Different car heights possible, e.g. vans, SUVs
  • For car weight up to 2,500 kg, higher loads are possible after consulting WÖHR
  • Easy operation with several control options, e.g. RFID chip or remote control
  • Suitable for residential and office bulding and for public parking
  • Following the idea of "Green-Parking"
